एचडीपीई भूमिगत गैस पाइप

घेरे के बाहर

पीएन4

PN5

पीएन6

PN8

पीएन10

पीएन12.5

पीएन16

पीएन20

PN25

एसडीआर41

एसडीआर33

एसडीआर26

एसडीआर21

एसडीआर17

एसडीआर13.6

एसडीआर11

एसडीआर9

एसडीआर7.4

दीवार की मोटाई (एन)

20

-

-

-

-

-

-

2.0

2.3

3.0

25

-

-

-

-

-

2.0

2.3

3.0

3.5

32

-

-

-

-

2.0

2.4

3.0

3.6

4.4

40

-

-

-

2.0

2.4

3.0

3.7

4.5

5.5

50

-

-

2.0

2.4

3.0

3.7

4.6

5.6

6.9

63

-

-

2.5

3.0

3.8

4.7

5.8

7.1

8.6

75

-

-

2.9

3.6

4.5

5.6

6.8

8.4

10.3

90

-

-

3.5

4.3

5.4

6.7

8.2

10.1

12.3

110

-

-

4.2

5.3

6.6

8.1

10.0

12.3

15.1

125

-

-

4.8

6.0

7.4

9.2

11.4

14.0

17.1

140

-

-

5.4

6.7

8.3

10.3

12.7

15.7

19.2

160

-

-

6.2

7.7

9.5

11.8

14.6

17.9

21.9

180

-

-

6.9

8.6

10.7

13.3

16.4

20.1

24.6

200

-

-

7.7

9.6

11.9

14.7

18.2

22.4

27.4

225

-

-

8.6

10.8

13.4

16.6

20.5

25.2

30.8

250

-

-

9.6

11.9

14.8

18.4

22.7

27.9

34.2

280

-

-

10.7

13.4

16.6

20.6

25.4

31.3

38.3

315

7.7

9.7

12.1

15.0

18.7

23.2

28.6

35.2

43.1

355

8.7

10.9

13.6

16.9

21.1

26.1

32.2

39.7

48.5

400

9.8

12.3

15.3

19.1

23.7

29.4

36.3

44.7

54.7

450

11.0

13.8

17.2

21.5

26.7

33.1

40.9

50.3

61.5

500

12.3

15.3

19.1

23.9

29.7

36.8

45.4

55.8

-

560

13.7

17.2

21.4

26.7

33.2

41.2

50.8

62.5

-

630

15.4

19.3

24.1

30.0

37.4

46.3

57.2

70.3

-

710

17.4

21.8

27.2

33.9

42.1

52.2

64.5

79.3

-

800

19.6

24.5

30.6

38.1

47.4

58.8

72.6

89.3

-

900

22.0

27.6

34.4

42.9

53.3

66.2

81.7

-

-

1000

24.5

30.6

38.2

47.7

59.3

72.5

90.2

-

-

1200

29.4

36.7

45.9

57.2

67.9

88.2

-

-

-

1400

34.3

42.9

53.5

66.7

82.4

102.9

-

-

-

1600

39.2

49.0

61.2

76.2

94.1

117.6

-

-

-
